Indef-iR Model Wire Rope Hoist
With an optimized modular design that is compliant with FEM/ISO standards, the iR Wire Rope Hoist is a low noise, long lasting product with a lifetime lubricated gearbox and hardened and ground gears. The product comes with higher motor ratings and can support up to 20T capacity and 24m height of lift. These are best suited for medium to heavy duty application and to increase the production capacity of the factory.
USPs
- Gearbox is coupled directly with the drum and high-quality service ensures high efficiency.
- High start stops per hour for demanding work application.
- High-quality, long-lasting motors for economical use with a provision for thermocouple and encoder adaptation if required by the customer.
- Upgradable to Industry 4.0 platform with Indef iQue feature.
Features
- Complies with FEM/ISO Classification.
- Compact, modular and flexible design that is economical in use.
- High performance gearbox with efficient motor.
- Fact acting, fail-safe AC/DC brakes.
- Available with Single and Dual speed options.
- Protective rope guide.
- Overload protection is a standard feature.
- Electromechanical overload protection and rotary limit switch (optional).
Benefits
- Better side approaches translate to better use of shed space.
- Compact, low noise & maintenance, multistage, lube immersed gearbox that is directly coupled with the rope drum for high efficiency.
- Aesthetically appealing product.
- Green technology IP55 enclosure based, optimised motor design to reduce noise and vibration.
- Adaptable design to meet customer specific requirements for components like motors, VFD, brakes, wire-rope etc.
- Fast-action, electromagnetic disc brakes to enhance safety.
- Dual Speed with frequency inverter on request allows frequency range with 1:10 speed reduction.
- Overload protection integrated into the hoist.
Wire Rope Electric Hoist Specifications
| Hoist Model | Capacity (Ton) | SWL in Ton & Design Duty Class | No. of Falls | Lifting Speed (MPM) | Motor (kW) | Head Room (mm) | Rope Dia (mm) | Monorail Beam | Cross Travel | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4m / M7 | 3m / M6 | 2m / M5 | 1Am / M4 | Width | Thickness | Motor | Speed | Wheel Dia | No. Wheels | |||||||
| IR-010-21-BT | 1 | 0.5 | 0.75 | 1 | 1.25 | 2 | 6 | 1.3 | 1150 | 8 | 90-180 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-020-41-BT | 2 | 0.5 | 1 | 2 | 2.5 | 4 | 3 / 3.3 | 1.3 | 1150 | 8 | 90-180 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-016-21-BT | 1.6 | 1 | 1.3 | 1.6 | 2 | 2 | 7 | 2.5 | 1250 | 8 | 90-180 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-032-41-BT | 3.2 | 2 | 2.5 | 3.2 | 4 | 4 | 3.5 / 4 | 2.5 | 1150 | 8 | 90-180 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-040-41-BT | 4 | 3 | 3.5 | 4 | 5 | 4 | 3 / 3.3 | 2.5 | 1150 | 10 | 90-180 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-050-41-BT | 5 | 4 | 4.5 | 5 | 5.5 | 4 | 4 | 4.1 | 1250 | 10 | 125-210 | 20 | 0.37×1 | 17 | 140 | 4 |
| IR-100-41-BT | 10 | 8 | 9 | 10 | 12.5 | 4 | 4 | 8.1 | 1650 | 13 | 125-210 | 20 | 0.37×2 | 17 | 140 | 4 |
| IR-150-41-BT | 15 | 12 | 13 | 15 | 16 | 4 | 3.5 | 10.5 | 2000 | 16 | 125-210 | 25 | 0.55×2 | 17 | 140 | 8 |
