Indef-HC Model Chain Hoist
Indef-C
The HC+ is Bajaj Indef’s answer to a new-gen solution for medium duty application requirements. With its tough built and robust Italian design, the HC+ is a low maintenance machine, built to resist heavy use and last a moderate operation time.
The HC+ range provides maximum durability and comes equipped with load-bearing capacity for use in light-duty, medium-duty and heavy-duty application. The hoist’s capacity ranges from 0.25T to 5T and offers a maximum height of lift of 40 meters.
USPs
- Compact Design
- Higher CDF and start-stops per hour
- Gearbox is housed in an aluminium alloy body and internal gears are made of carburised hardened steel alloy and greased for low noise
- Grip-friendly cylindrically shaped lower hook with thrust bearing
- Standard four stage gear cam limit switch
- Surface hardened blackodized and corrosion free strong load chain
- Equipped with powerful AC brake with high braking torque for fail-safe operations
Features
- Supports a range of 0.25T to 5T
- Tested for SWL 25% overload condition
- Rugged Italian design
- Gravity dye cast gearbox body and case
- Precision machine cut case, hardened steel alloy gears and load chain wheel
- Geared rotary limit switch and overload slipping clutch
- Easily adjustable upper and lower hook positions
- Imported Grade 80 surface hardened load chain
- Single speed/dual speed robust brake motor
Benefits
- Suitable for varied application
- Assured safety and reliability
- Improved performance and reduced dead weight
- Long life and smooth, low noise operation
- Travel limits to prevent overloading
- Protection against overloading
- Aesthetically superior and rust-free
- Wear resistant for a longer chain life
